Block: Dart Big M Sportsman, 4.500" Bore, 9.8" Deck Height
Crankshaft: Smeding 4340 Forged Steel, Internal Balance, 4.250" Stroke
Rods: Smeding 4340 Forged Steel H-beam with 7/16" Bolts, 6.385" Length
Pistons: Icon 4032 Forged Aluminum, 10.0:1 Compression, Coated Skirts
Rings: Plasma-Moly Top, Low Friction Oil, 1/16” x 1/16” x 3/16”
Camshaft: Smeding Hydraulic Roller, .614”/.614” Lift, 253°/263° Duration @ .050”
Rocker Arms: Smeding 1.7 Ratio, 7/16" Stud, Full-Roller
Intake: Edelbrock Victor Jr. Single Plane
Cylinder Heads: Smeding 360cc Intake Port, 2.30"/1.88" Valves, 120cc Chambers
Warranty: 3 Year, Unlimited Miles

Torque Converter: 2,600-3,000rpm Stall Recommended
